30W solar power panel 20A battery solar power system for CCTV cameras solar power CCTV cameras no power security

Model: 30W20A
Place of Origin: Guangdong,China (Mainland)
Products Name: Solar power system
Peak power: 30W
Peak voltage: 18V
Peak power supply: 1.74A
Solar cells: 36pcs monocrystalline silicon
Battery type: lithium polymer battery
Battery capacity: 20AH
Operation voltage: 8.5-12.6V
Charging voltage: 12-12.6V
Recharging current: 0.5-10A

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Products : 30W solar  power  panel 20A  battery solar  power system for  CCTV cameras  solar power CCTV cameras no power security

Features :

A complete set of solar systems (including batteries), very easy to use.

Installation is simple, can be used with many kinds of IP cameras.

efficiency of solar cell is higher than 96.8%.

Those high quality materials such as toughened glass, EVA, waterproofed solar board and aluminum alloy line protecting all components from harsh environment.


Specification :

Solar panel

Peak power(Pmax)

30W

Peak voltage(Vmp)

18V

Open circuit voltage

21.6V

Peak power supply

1.74A

Short circuit power supply

1.91A

Solar cells

36PCS monocrystalline silicon(125x41.66mm)

Max System Voltage

1000V DC(IEC)/600V(UL)

WeatherProof Level

IP 65

Operating temperature

-40℃~+85℃

Dimension(mm)

50x43x3CM

Battery type

Lithium polymer battery

Battery capacity

20AH

Operating voltage

8.5~12.6V

Continuous current

≤20A

Instantaneous current

50A

Charging voltage

12~12.6V

recharging current

0.5~10A

Interface line

Discharge: T type / charge: DC type

Cycle life

1000 times

Operating temperature

-20℃~+60℃

Battery weight

2kg

Battery size(mm)

7.5x11x7.5CM

safety

Overcharge protection, over discharge protection, short circuit protection, excessive current protection

General specification

Bracket material

iron

Installation

Rack mounting

Size(W×D×H)(mm)

55×50×20CM

Weight(kg)

8.5kg
